Brand Name : yunyi
Certification : CE
Place of Origin : china
MOQ : 1
Payment Terms : L/C,T/T,Western Union
Delivery Time : 8~10 work days
Packaging Details : aluminium alloy box
Series Core Advantages and Features
1. Advanced Servo Pressure Control Technology
Utilizes imported high-precision servo pressure regulating valves. Precise control of main valve actions via pilot valves enables rapid, stable pressure regulation without overshoot.
Eliminates the stepwise pressure changes inherent in traditional on/off valves, delivering smooth, continuous pressure control that significantly enhances calibration efficiency and accuracy.
2. High Integration and Modularity
Integrated Design: Combines vacuum, pneumatic, and hydraulic functions in a single unit for broad coverage.
Modular Pressure Modules: Standard configuration includes multiple SDP modular smart digital pressure calibrators. Utilizes imported high-precision sensors with excellent long-term stability, wide measurement range, and independent operation capability.
Modular Pressure Interfaces: Multiple M20×1.5 standard female threaded ports enable simultaneous calibration of multiple instruments.
3. Intelligence and Automation
Fully Automatic Pressurization: Built-in dynamic balancing technology ensures instantaneous pressure stabilization without leakage.
Integrated HART Handheld Communicator: Enables direct management of basic information, range migration, zero point, and temperature calibration for HART smart transmitters without additional equipment.
Robust Communication Capabilities: Interfaces with host computer software for automated data acquisition, processing, storage, and result printing, facilitating quality management.
4. Flexible Multi-Function Display
Equipped with multiple independent standard display meters, simultaneously showing real-time parameters like pressure, current, and voltage for intuitive monitoring.
High-resolution touchscreen provides an intuitive human-machine interface with Chinese display support for simplified operation.
5. Tailored for Diverse User Needs
The series offers multiple configurations including SPMK2000N (Standard) and SPMK2000N-SY (Enhanced) to meet varying budget, accuracy, and channel requirements.
Standard Equipment Configuration
SDP Modular Intelligent Digital Pressure Calibrator: 8 units, accuracy class 0.05, covering multiple ranges from vacuum to high pressure.
Master Control System: Includes digital pressure drive module and 22-inch LCD display.
Computer and Printer: For data management, report generation, and printing.
Servo Pressure Control System: Enables precise forward control, ensuring rapid and stable pressure.
Typical Application Scenarios
This series of calibration benches is widely applicable for the verification and calibration of the following instruments:
Various pressure transmitters and differential pressure transmitters (including HART protocol smart instruments)
Precision pressure gauges, general-purpose pressure gauges, pressure-vacuum gauges
Pressure sensors, pressure switches
Digital pressure meters
Laboratories or production workshops requiring simultaneous calibration of multiple pressure instruments
Why Choose Us?
Technology Leadership: True servo pressure control technology delivers a revolutionary pressure management experience.
Efficient and Time-Saving: Multi-channel design supports parallel calibration, while automated processes minimize manual intervention.
High ROI: A single unit covers vacuum, pneumatic, and hydraulic testing—one machine for multiple applications, saving procurement and space costs.
Stable and Reliable: Core pressure modules utilize imported sensors for exceptional long-term stability and low maintenance costs.
Future-Ready: Digital-ready design supports data management and HART communication, meeting Industry 4.0 and smart factory requirements.
|
|
